ESmart Digital Lock - Cabinet 1P - RFID

Easy to program - no need for software or PC

Automatic on lock function

Easy to install

For shutter thickness: 15 - 22 mm

Frequency: 125KHz

Working current: 180mA ~ 280mA

Working temperature: 0°C ~ 40°C

Working voltage: 4.5V

Working humidity: 20% ~ 80%

ABS front case and lock housing

Function mode: Manual close mode Automatic close mode Public user mode

Manual close mode

Automatic close mode

Public user mode

Function card: Management (Programming) Card - is used to create user card User card - is the key of the lock

Management (Programming) Card - is used to create user card

User card - is the key of the lock

The same RF can be shared by all the locks

Power Supply: 3 standard AAA alkaline batteries (not included)

3 standard AAA alkaline batteries (not included)

Color: Black
