Schneider Electric Pack of 4 Isolator SW 3P 40A 415VAC SKU-AECMCB-A9KS15340BQ

SKU: SKU-AECMCB-A9KS15340BQ

Product or component type Switch disconnector Device short name - SW Device application - Control Poles description - 3P Utilisation category - AC-22A

Price Starting From

Old price: ₹ 2,799.00

Price: ₹ 2,761.65

Click below to Proceed to bulk order purchase and enjoy discounts up to 50%

Click below toProceed to bulk order purchase and enjoy discounts up to 70%

[Ie] rated operational current	40 A at 415 V AC 50/60 Hz
[Ue] rated operational voltage	415 V AC 50/60 Hz
Quantity per set	Set of 4
[Icm] rated short-circuit making capacity	0.6 kA switch-disconnector alone
[Icw] rated short-time withstand current	480 A during 300 ms
[Ui] rated insulation voltage	500 V AC 50/60 Hz
[Uimp] rated impulse withstand voltage	4 kV conforming to IEC 60947-3
control type	Toggle
Mounting mode	Fixed
mounting support	DIN rail
Comb busbar and distribution block compatibility	Downstream: biconnect
9 mm pitches	6
height	81 mm
Width	54 mm
Depth	68.5 mm
Net weight	0.36 kg
Colour	White
Mechanical durability	20000 cycles
Electrical durability	10000 cycles
Connections - terminals	Tunnel type terminals (downstream) - 1...35 mm² - rigid Tunnel type terminals (downstream) - 1...25 mm² - flexible Tunnel type terminals (upstream) - 1...35 mm² - rigid Tunnel type terminals (upstream) - 1...25 mm² - flexible
wire stripping length	9 mm
tightening torque	3.5 N.m

Environment
Standards	IEC 60947-3
IP degree of protection	IP20
Pollution degree	2
Tropicalisation	2
Relative humidity	95 % at 55 °C
ambient air temperature for operation	-5…55 °C
Ambient air temperature for storage	-25…85 °C

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	8 cm
Package 1 Width	5 cm
Package 1 Length	8 cm
Package 1 Weight	1.002 kg
